RPQ3 SPECIFICATIONS
Max Gain at 1 kHz: 85 dB
EIN (Max gain, 22 Hz to 22 KHz, unweighted):
-130 dBu (typical), 40 Ω source
-128 dBu (typical), 150 Ω source
Frequency Response:
30 dB gain: (-0.6 dB 10 Hz, -3 dB 160 kHz)
85 dB gain: (-3 dB 10 Hz and 160 kHz)
THD+N: 0.0018% (1kHz, 22 Hz-22 kHz @30 dB Gain +4 dBu output)
XLR Output Max Level: +27 dBu into 600 Ω load
Input Impedance: 11.3 kΩ (with Phantom), 68 kΩ (no Phantom)
Output Impedance: 50 Ω
Max Input Signal Level: +20 dBu (minimum gain)
Stepped Gain Control: 12-position switch from +7 dB to +65 dB
Output Trim: Continuously variable from 0 dB to +20 dB
EQ Circuitry:
First order shelving response
20 dB max boost/cut high range, 10 dB max boost/cut low range
Low frequency sweep continuously variable 40 Hz to 675 Hz
High frequency sweep continuously variable 2 kHz to 28 kHz
Input and Output XLR Polarity: Pin 2 hot
LED Signal Level Indicators:
Green LED ≅ -20 dBu;
Yellow LED = 0 dBu;
Red LED ≅ +20 dBu (clipping +27 dBu)
